ZJA6KY 6000L/H Hot Sale Two Stage Vacuum Transformer Oil Purifying Machine
| Place of Origin | China Mainland |
|---|---|
| Brand Name | Delta |
| Certification | ISO9001 |
| Model Number | ZJA |
| Minimum Order Quantity | 1 set Oil Purifying Machine |
| Price | USD1.0 Oil Purifying Machine / set |
| Packaging Details | Oil Purifying Machine is Packed in wooden case and container |
| Delivery Time | Within 30 days after the order is confirmed |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 100 sets Oil Purifying Machine / month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Flow Rate | 30L/Min, 50L/Min, 100L/Min, 150L/Min, 200L/Min | Description | ZJA6KY 6000LH Hot Sale Two Stage Vacuum Transformer Oil Purifying Machine |
|---|---|---|---|
| Functions | Remove Water, Gases, Acid, Particles From The Oil | Advantages | High Working Vacuum, High Filtration Speed, Oil |
| Structure | It Can Be Sealed Or Movable With Trailer | Application Field | Electrical Servicer |
| Working Pressure | <0.5MPa | Working Vacuum Degree | -0.08 ~ -0.0999MPa |
| Temperature Control Range | 20 - 80 Celsius | Power Supply | Three Phase, 380V, 50Hz, Or As Quested |
| Oil Quality After Purifying | Breakdown Voltage >60kv | Oil Quality After Purifying 01 | Water Content 5-10ppm |
| Trade Term | EXW, Fob, DDU, CNF, CIF, Etc. | Delivery Lead Time | 30 Days |
| Shipping Method | By Sea | Condition | Totally New |
| Language | English |
Product Description
ZJA 6000L/H Hot Sale Two-Stage Vacuum Transformer Oil Purifying Machine
Introduction:
Transformer oil is very important to the reliability, performance, and lifetime of a transformer. The oil should be free from moisture, dissolved gases, particles, etc. Even some new oils may require treatment to an acceptable level before being injected into the transformer;
Our ZJA 6000L/H Hot Sale Two Stage Vacuum Transformer Oil Purifying Machine is professional for the treatment of transformer oil, It can efficiently remove water, gases, acid, particles, etc. from the oil.
With the advantages of a high working vacuum, high filtration speed, and oil quality protection, the filter advanced the oil treatment technique and equipment performance and can raise the puncture voltage to over 35V.
ZJA 6000L/H Hot Sale Two Stage Vacuum Transformer Oil Purifying Machine can be installed by sealed regular or movable with a trailer, so it is suitable to treat oil, fill oil in a vacuum chamber, and circulate dry hot oil when the large transformer is being installed and overhauled.
Parameters:
| Parameters | Unit | 1.8KY | 3KY | 6KY | 9KY | 12KY | 18KY |
| Flow Rate | L/H | 1800 | 3000 | 6000 | 9000 | 12000 | 18000 |
| Working Vacuity | Pa | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 |
| Working Pressure | Mpa | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
| Temperature Range | ºC | 45-65 | 45-65 | 45-65 | 45-65 | 45-65 | 45-65 |
| Power Supply | 50Hz | 380V | 3-Phase | 4-Wire | or as request | ||
| Total Power | KW | 16 | 36 | 70 | 100 | 150 | 200 |
| Inlet/Outlet Diameter | mm | 20/20 | 25/25 | 32/32 | 40/40 | 50/50 | 65/65 |
| Length | mm | 1600 | 1800 | 2200 | 2500 | 2800 | 3450 |
| Width | mm | 1250 | 1450 | 1600 | 1950 | 2150 | 2600 |
| Height | mm | 2000 | 2200 | 2450 | 2700 | 3000 | 3000 |
| Weight | Kg | 500 | 700 | 1460 | 1800 | 2400 | 4000 |
Features:
One pot with a two-stage vacuum-segregating space comes under different pressure to keep the oil line balanced between the two stages.
Imported vacuum pumps from Europe have the highest level in the world and high air pump speed guarantees high working vacuity.
The new technology of vacuum-segregating adopts a particular spinning disk and stainless steel machine with a dehydration and air pump.
Using a new type of heating equipment which can reduce heating burthen and extend oil life.
Oil level control adopts the photoelectric way in which the main components are imported from Switzerland.
Customers can choose equipment equipped with all or partly imported components.
It's equipped with filter assemblies imported from Italy.
All pumps must be airproofed by our factory, moreover running without noise and leakage. extended oil life.
