FRC Portable DC or AC High Voltage Divider for Pulse HV Testing

  • FRC Portable DC or AC High Voltage Divider for Pulse HV Testing
  • FRC Portable DC or AC High Voltage Divider for Pulse HV Testing
  • FRC Portable DC or AC High Voltage Divider for Pulse HV Testing
Place of Origin China
Brand Name Delta
Certification ISO9001
Model Number FRC
Minimum Order Quantity 1 set
Price USD1.0
Packaging Details FRC Portable DC or AC High Voltage Divider is packed in veneer case
Delivery Time 10 days
Payment Terms Western Union, T/T, L/C
Supply Ability 100 sets each month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Portable, Convenient To Use And Carry Item Name FRC Portable DC Or AC High Voltage Divider For Pulse Hv Testing
Description DC Or AC High Voltage Divider For Pulse Hv Testing Application Field Electrical Industry
Weight 8kg, 10kg, 18kg, 25kg Dimension 22cm*22cm*60/75/140/180cm
AC Voltage 50kv, 100kv, 200kv, 300kv Powery Supply 220V, 50Hz
Warranty Period 1 Year
Leave a Message
Product Description

Frc Portable DC or AC High Voltage Divider for Pulse Hv Testing

Introduction:

  • FRC digital divider is one kind of universal high-voltage measuring instruments. It can be used in power systems, electrical appliances, electronic equipment manufacturing sector to measure AC high-voltage and DC high-voltage under the industrial frequency.
  • FRC digital divider is made up of high-vlotage measuring part and low-voltage measuring instrument. They are separate when working. It works safely and reliably.
  • FRC digital divider is a type of portable structure. It packs with aluminum alloy box to be chassis. It's very convenient to use and carry.



Parameters:

Model

FRC-50

FRC-100

FRC-200

FRC-300

Range

AC

50

100

200

300

(kV)

DC

70

140

280

400

Accuracy

AC

1.50%

1.50%

1.50%

1.50%

DC

1.00%

1.00%

1.00%

1.00%

Impedance

R(MΩ)

200

400

800

1200

Capacitance

C(PF)

/

200

100

75

Size(cm)

　

22*22*60

22*22*75

22*22*140

22*22*180

Weight

　

8

10

18

25

Working Environment

Temperature:0-40ºC, Relative humidity:<85%





FRC Portable DC or AC High Voltage Divider Features:
